Rāmis (mūža garantija) – Advanced-Grade Composite, flat mount disc, 12x142mm thru-axle
Dakša – Advanced–Grade Composite, Full-Composite OverDrive one Steerer, flat mount disc 12mm thru-axle
Stūres gultņi – NO.56E alloy wo crown wo LG W/MR180 BEARING H=10.4, top cap – G1SC01 wo LG wo 26 nut w M6x30 STL bolt B.BLK, Matt Black
Stūre – Giant Contact XR D-Fuse, 31.8mm, 5-degree back sweep, flare drop, alloy XS: 400mm, S: 400mm, M: 420mm, L: 420mm
Stūres rokturi – Liv All Condition
Iznesums – Giant Contact AeroLight, -10 degree, alloy XS: 50mm, S: 60mm, M: 70mm, L: 80mm
Stute – Post Moderne, dropper, 30mm suspension XS: 75mm, S: 75mm, M: 75mm, L: 100mm
Sēdeklis – Liv Approach with GIANT patented UniClip & ParticleFlow technology
Pārslēdzēju rokturi – SRAM Apex, 1×12 speed
Priekšējais pārslēdzējs – N/A
Aizmugurējais pārslēdzējs – SRAM Apex XPLR 12 speed
Bremzes – SRAM Apex hydraulic, Giant MPH rotors [F]160mm, [R]160mm
Bremžu rokturi – SRAM Apex hydraulic, Giant MPH rotors [F]160mm, [R]160mm
Kasete – SRAM PG-1231 D1 XPLR, 12-speed, 11×44
Ķēde – SRAM Apex 12SCN-APX-D1
Klaņi – SRAM Apex 1 Wide, 40t XS: 165mm, S: 170mm, M: 172.5mm, L: 172.5mm
Monobloks – SRAM DUB, Press Fit
Rati – Giant P-X2 Disc, 700C Wheelset, 25mm inner width, 12mm Thru Axles
Riepas – Maxxis Rambler 700x45C tubeless
Papildus aprīkojums – Giant 1x chain guide, tubeless prepared, 53mm max tire size in long flip chip position, 45mm max tire size in short flip chip position, ISC clamp, integrated down tube storage bag
| XS |
150–163 cm |
| S |
159–169 cm |
| M |
164–175 cm |
| L |
170–181 cm |
| |
|
| |
|
